Industrial X-Ray Inspection System

Explore a practical range of microfocus inspection equipment for electronics manufacturing, SMT lines, PCB review, semiconductor packages, casting analysis, and component counting.

VMAX product families support different inspection environments. Select the system category that matches the sample structure, production flow, and evidence required.

XST 6800 industrial X-ray inspection system
01 / 05

XST 6800

A high-resolution offline system for BGA, solder joint, and electronic component inspection, with programmable image capture, measurement, and image analysis.

  • 100 kV X-ray source, 5 μm focal spot, and automatic tube sleep protection
  • 560 × 530 mm sample size and 5 kg maximum sample weight
  • 200× geometric magnification, 2000× system magnification, and receiver support for 60° angled inspection
Discuss this inspection requirement ↗
XST 6500 industrial X-ray inspection system
02 / 05

XST 6500

A compact cabinet system for space-constrained electronics inspection, combining high-resolution imaging, automatic navigation, and BGA measurement.

  • 90 kV X-ray source, 5 μm focal spot, and high-definition flat-panel detector
  • 420 × 420 mm sample size and 5 kg maximum sample weight
  • 100× geometric magnification and 1000× system magnification
Discuss this inspection requirement ↗
AXST 8800 industrial X-ray inspection system
03 / 05

AXST 8800

An online X-ray inspection system for SMT lines with automated loading and unloading, automatic defect analysis, and a high-definition flat-panel detector.

  • 100 kV X-ray source, 5 μm focal spot, and automatic tube sleep protection
  • 850 mm PCB rail width and 400 × 500 mm inspection range
  • Up to 400 × 650 mm capacity, 200X digital magnification, and 1200X system magnification
Discuss this inspection requirement ↗
XST 8600 / X-860L industrial X-ray inspection system
04 / 05

XST 8600 / X-860L

Casting inspection systems for automotive die-castings, porosity, and measurement-hole applications with real-time imaging and multi-angle rotation.

  • XST 8600: 160 kV high-power X-ray source, 360° disc rotation, and 35° C-arm rotation
  • X-860L: 100 kV Hamamatsu integrated X-ray source with automatic reset and measurement-hole analysis
  • Optional automated casting system with 160 kV source, optional 225 kV source, and 400 × 400 mm field of view
Discuss this inspection requirement ↗
XCR 8800 / AXCT 8800C industrial X-ray inspection system
05 / 05

XCR 8800 / AXCT 8800C

Offline and online component counting systems for SMT reel counting, code reading, marking, and MES/SPC data workflows.

  • XCR 8800: 40–80 kV, 1–1.25 mA; four 7-inch reels per cycle or one 13/15-inch reel per cycle
  • Intelligent code reading and automatic marking; results can be printed, saved, and reported to MES
  • AXCT 8800C: supports 7–15 inch reels with a 350 × 350 mm inspection range
Discuss this inspection requirement ↗

Inspection solutions for electronics manufacturing

Microfocus X-Ray Inspection Machine

Use high-resolution imaging to review hidden structures and solder joints without dismantling the sample.

SMT X-Ray Inspection Equipment

Support offline analysis and online SMT inspection workflows for PCB assemblies and production lines.

PCB X-Ray Inspection Solution

Connect image evidence, measurement, and technical discussion for PCB inspection requirements.

Discuss Your Application →
